Tabloid vs A3: A3 Is 0.69 in Wider, Tabloid Is 0.46 in Taller
The two sheets compared
-
ASME Y14.1 (ANSI B)
Tabloid paper (ANSI B)
11 × 17 in (279.4 × 431.8 mm)
-
ISO 216
A3 paper
11.69 × 16.54 in (297 × 420 mm)
The short answer
- Tabloid (ANSI B)11×17 in (279.4×431.8 mm)
- A311.69×16.54 in (297×420 mm)
- DifferenceA3 is 0.69 in (17.6 mm) wider; Tabloid is 0.46 in (11.8 mm) taller. Neither fits inside the other.
See the sizes in AR (shown as boxes)
The two sizes as boxes at their published dimensions
Preparing 3D…
1 Tabloid2 A3
On a phone, the "View in your room (AR)" button places the boxes in your room. The boxes are locked to the published dimensions and cannot be resized. They show size only and are not 3D replicas of the products.
Drawn to the same scale
Dimensions side by side
| Item | Tabloid (ANSI B) | A3 | Difference |
|---|---|---|---|
| Width (short side) | 11 in / 279.4 mm | 11.69 in / 297 mm | A3 is 0.69 in (17.6 mm) wider |
| Height (long side) | 17 in / 431.8 mm | 16.54 in / 420 mm | Tabloid is 0.46 in (11.8 mm) taller |
| Area | 187.0 in² / 1206.4 cm² | 193.3 in² / 1247.4 cm² | A3 is 3.4% larger |
| Aspect ratio | 1 : 1.545 | 1 : 1.414 | A3 is closer to square |
Inch lengths for A3 are converted at 1 in = 25.4 mm and rounded to two decimal places; areas are rounded to one decimal place. Tabloid's millimeter values (279.4×431.8 mm) are exact.
Pixels and points
| Size | 150 dpi | 300 dpi | 600 dpi | Points (pt) |
|---|---|---|---|---|
| Tabloid (11×17) | 1650 × 2550 px | 3300 × 5100 px | 6600 × 10200 px | 792 × 1224 pt |
| A3 | 1754 × 2480 px | 3508 × 4961 px | 7016 × 9921 px | 842 × 1191 pt |
Pixel counts are the inch dimensions multiplied by the dots per inch and rounded to whole pixels (A-series sizes are defined in millimeters and divided by 25.4 first). They say how many pixels fill the sheet at that density, not what any printer or service requires. Points are 1/72 in, the unit page-layout and PDF software uses for page size.
What the numbers mean
Neither sheet contains the other. A3 is wider, Tabloid is taller, so a page laid out for one size does not fit the other at 100%.
A Tabloid layout on A3 paper loses 0.46 in (11.8 mm) at the top. Scaling to 97% (420 ÷ 431.8) fits it (the scaled page is about 271.8 mm wide), leaving 25.2 mm of blank width in total, about 12.6 mm on each side if centered. An A3 layout on Tabloid paper loses 0.69 in (17.6 mm) on the right. Scaling to 94% (279.4 ÷ 297) fits it.
A3's 1 : √2 ratio means two A3 sheets side by side make exactly one A2, and one A3 folded in half makes one A4. Tabloid has a halving rule of its own: folded in half, one Tabloid sheet makes one Letter sheet (8.5×11 in). What the ANSI sizes do not keep is the shape. The long side is about 1.55 times the short side on Tabloid and about 1.29 times on Letter, so a layout does not carry over between the two without new margins. In the A series the shape stays the same at every step.
Product links
FAQ
Is Tabloid (11×17) bigger than A3?
Neither sheet fully contains the other. Tabloid (11×17 in / 279.4×431.8 mm) is 0.46 in (11.8 mm) taller than A3 (11.69×16.54 in / 297×420 mm), but A3 is 0.69 in (17.6 mm) wider than Tabloid. A3 has a slightly larger area: 1247.4 cm² vs 1206.4 cm².
Can I print a Tabloid document on A3 paper?
Not at 100% scale. Tabloid is 0.46 in (11.8 mm) taller than A3, so the top of a Tabloid layout falls off an A3 sheet. Scaling to about 97% (420 ÷ 431.8) fits it (the scaled page is about 271.8 mm wide), leaving 25.2 mm of blank width in total, about 12.6 mm on each side if centered.
Can I print an A3 document on Tabloid paper?
Not at 100% scale. A3 is 0.69 in (17.6 mm) wider than Tabloid, so the right side of an A3 layout falls off a Tabloid sheet. Scaling to about 94% (279.4 ÷ 297) fits it, with some blank space at the top and bottom.
What is Tabloid paper called in the ISO system?
There is no ISO equivalent. Tabloid is ANSI B (11×17 in) defined in ASME Y14.1. The closest ISO size is A3 (297×420 mm), but the two formats are not interchangeable at 100% scale.
Is Ledger the same size as Tabloid?
Yes — the same 11×17 in (279.4×431.8 mm) sheet, ANSI B in ASME Y14.1. The two names refer to the two orientations of that sheet: the ANSI Blog describes ANSI B as coming "in two forms: ledger and tabloid, at 11”x17” and 17”x11”, respectively". Whichever of the two names a printer driver or a print shop uses, the sheet is 11×17 in, and everything on this page applies to it.
See also: A4 vs Letter — the A-series meets the ANSI series one step smaller. ANSI Paper Sizes A–E — all five ANSI sizes drawn to the same scale with aspect ratio compared to ISO A.
Sources
- Tabloid (ANSI B): ASME Y14.1 defines ANSI B as 11×17 in (ANSI Blog, "Standard Paper Sizes – ISO and ANSI Formats", checked 2026-09-27; re-read 2026-09-30 for the Ledger wording: "ANSI B comes in two forms: ledger and tabloid, at 11”x17” and 17”x11”, respectively").
- A3: ISO 216 (A series), 297×420 mm. Japan's JIS P 0138 uses the same value.
- Credit card: ISO/IEC 7810 ID-1, 85.60×53.98 mm (rounded to 85.6×54 mm in the figure caption).
